PB-Ⅰ/PB-Ⅱ平板閘門是粉料、晶粒料、小顆粒料的流量輸送控制的主要設備。廣泛適用于冶金、礦山、建材、糧食、化工等行業。PB-Ⅰ平板閘門配備電動、氣動、電液動推桿作為驅動裝置，是控制流量大小，切斷迅速的設備。
Flat valve is a main equipment to control and convey powder material, crystal material and small grain material.
It is widely used in metallurgical, ore, building material，foodstuff and chemical industry etc. The valve has motorized, pneumatic and motorized and hydraulic handspike as driving device. It is an ideal equipment to control flow and quick cutting.

結構特點：
        PB-Ⅰ/PB-Ⅱ平板閘門具有結構簡單，操作自如，密封性能優良，局部阻力損失小，切斷快，維護保養方便，不易變形等特點。
Structure features
        It is characterized by simple structure, free operation, excellent sealing, small resistance, quick cutting and convenient maintenance and not easy to deform etc.

工作原理：
　　平板閘門主要由執行機構、閥體、插板、密封裝置、行程開關等部件組成。運行時輸出指令（電源或氣源）給執行機構，由執行機構帶動插板向外推出，達到工況需要位置，轉動行程開關停止，由行程開關反饋信號（開關信號）給控制室。反之則關閉插板閥（向內推進）。


Work principle
        Flat valve is mainly composed of actuator, valve body, inserting plate, sealing device and travel switch etc. When driving, output instructions(power or gas source) to actuator. Actuator drive inserting plate outside and meet work condition. Otherwise close inserting valve (inside toward).

傳動裝置參數(The parameter of driving device)

PB-Ⅰ連接尺寸：

 PB-Ⅱ連接尺寸：
